Multilayer Board
PCB prototyping/batch customization for 1-26 layers with fast delivery in as little as 72 hours.
1-2 HDI (1-2 order HDI), thick copper customization, impedance matching, and 1-meter large boards.
Four-layer board
Delivery time: 4 days
1-2 order HDI, multi-level impedance, customized lamination
Board thickness: 0.8-2.4mm, copper thickness 1-10oz
Maximum size: 1000*500mm
Free shipping nationwide, full AOI inspection
six-layer board
Delivery time: 5 days
Blind and buried vias, nickel-palladium-gold plating
Board thickness: 1.0-2.4mm, copper thickness 1-10oz
Minimum hole diameter: 0.15mm, minimum line width: 3mil
Eight-layer board
Delivery time: 5 days
Blind and buried vias, TG130-180
Board thickness: 1.2-2.4mm, copper thickness: 1-10oz
Minimum hole diameter: 0.15mm, minimum line width: 3mil
